E550028 ECHU UL758 standard 1000V UL3644 single conductor silicone rubber insulated cable with tinned copper

Name: E550028 ECHU UL758 standard 1000V UL3644 single conductor silicone rubber insulated cable with tinned copper
Brand: Shanghai ECHU Wire and Cable Co., Ltd
SKU: UL3644
Price: 2.27 USD
Availability: InStock

Brand Name:	ECHU
Model Number:	UL3644
MOQ:	305M
Price:	USD1.265-USD3.639/M
Payment Terms:	T/T,, L/C
Supply Ability:	100000km/week

Detail Information

Product Description

Detail Information

Place of Origin:

Shanghai China

Certification:

Color:

Yellow, Green, Yellow/green, Black, White.....

Insulation:

Silicon Rubber

Voltage:

1000V

Temperature:

-60ºC To +200ºC

Packaging Details:

100M/Roll or according to customer requirement

Supply Ability:

100000km/week

Product Description

UL3644 Single-Conductor Silicone Rubber AWM Cable UL3644 is high-temperature silicone wire complying with UL758 Appliance Wiring Material standard.

Construction Conductor: Solid or Class 5 flexible stranded bare / tinned copper (30AWG ~ 1000kcmil); Insulation: Extruded silicone rubber (SR).
Electrical & Thermal Ratings Rated Voltage: 1000V AC Rated Temperature: 150°C or 200°C (dry locations) Operating temperature range: -60°C ~ +200°C
Flame Performance Self-extinguishing, meets UL FT2 horizontal flame test.
Key Features Excellent flexibility, outstanding heat resistance, low-temperature resistance, ozone resistance, UV resistance and chemical resistance. Stable dielectric property; uniform insulation thickness for easy stripping. Halogen-free, RoHS compliant.
Typical Applications Internal wiring for household appliances, heating devices, ovens, motors, transformers, inverters, lighting equipment, new energy equipment and general industrial machinery under high-temperature conditions.

Item	UL3644 Silicone rubber cables
Conductor	Bare copper
Insulation	Silicone Rubber
Rated Voltage	1000V
Temperature Range	Maximum Working Temperature: -60ºC to +200ºC
Color	Optional
Application	This cable is mainly used for internal wiring in high temperature areas such as household appliances, lighting, heaters, motors, dryers, and ovens
