E550028 ECHU UL Rubber Cable Single conductor with extruded EPDM insulaiton UL3340 26AWG -500Kcmil 125 or 150 deg C, 600 Vac, 750 Vdc with UL certificate

Name: E550028 ECHU UL Rubber Cable Single conductor with extruded EPDM insulaiton UL3340 26AWG -500Kcmil 125 or 150 deg C, 600 Vac, 750 Vdc with UL certificate
Brand: Shanghai ECHU Wire and Cable Co., Ltd
SKU: UL3340
Price: 6.11 USD
Availability: InStock

Brand Name:	ECHU
Model Number:	UL3340
MOQ:	300M
Price:	USD0.11-USD12.88/M
Payment Terms:	TT, Western Union, L/C
Supply Ability:	100000km/week

Detail Information

Product Description

Detail Information

Place of Origin:

Shanghai, China

Certification:

Type:

UL3340

Insulation:

EPDM

Conductor:

Stranded Copper

Certificate:

Certificate No.:

E550028

Voltage:

600V， 750V

Temperature:

125℃, 150℃

Packaging Details:

wooden reel

Supply Ability:

100000km/week

Product Description

EPDM insulation Cable UL CABLE UL3340

UL Approval

Rating: 125 or 150 deg C, 600 Vac, 750 Vdc, Horizontal flame.

Conductor: 26 AWG - 500 kcmil, solid or stranded

Standard: Appliance Wiring Material UL 758

Application:

Motor Leads and Internal Wiring of Appliances where exposed to temperatures not exceeding 125 deg C. Where no flexing occurs either after installation of during servicing, temperatures not to exceed 150 deg C.

E550028 ECHU UL Rubber Cable Single conductor with extruded EPDM insulaiton UL3340 26AWG -500Kcmil 125 or 150 deg C, 600 Vac, 750 Vdc with UL certificate 0

Type	Size	O.D.(mm)	Weight(KG/KM)
UL3340	26AWG	3	13
UL3340	25AWG	3.1	13
UL3340	24AWG	3.2	14
UL3340	23AWG	3.2	15
UL3340	22AWG	3.3	16
UL3340	21AWG	3.4	17
UL3340	20AWG	3.5	19
UL3340	19AWG	3.6	21
UL3340	18AWG	3.7	23
UL3340	17AWG	3.9	26
UL3340	16AWG	4	30
UL3340	15AWG	4.2	34
UL3340	14AWG	4.4	39
UL3340	13AWG	4.7	46
UL3340	12AWG	4.9	53
UL3340	11AWG	5.4	65
UL3340	10AWG	5.7	78
UL3340	9AWG	6.1	95
UL3340	8AWG	7.2	124
UL3340	7AWG	7.7	148
UL3340	6AWG	8.8	186
UL3340	5AWG	9.5	225
UL3340	4AWG	10.2	272
UL3340	3AWG	11.2	332
UL3340	2AWG	12.1	405
UL3340	1AWG	14.2	529
UL3340	1/0AWG	15.3	645
UL3340	2/0AWG	16.7	793
UL3340	3/0AWG	18.2	977
UL3340	4/0AWG	19.9	1207
