UL1007 18AWG electrical wire electrical cable ECHU Cable E312831

Name: UL1007 18AWG electrical wire electrical cable ECHU Cable E312831
Brand: Shanghai ECHU Wire and Cable Co., Ltd
SKU: UL1007
Price: 0.04 USD
Availability: InStock

Brand Name:	ECHU
Model Number:	UL1007
MOQ:	305m/Roll
Price:	USD0.035-USD0.219/M
Payment Terms:	T/T, L/C
Supply Ability:	100000km/week

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Insulation:

PVC

Conductor:

Stranded Copper

Type:

UL1007

Voltage:

300V

Temperature:

105℃

Packaging Details:

wooden boxes

Supply Ability:

100000km/week

Product Description

UL Approval: E312831, ECHU Cable
Description:
Related temperature: 80 degree
Rated voltage: 300V
Reference standard:
UL subject 758 & UL1581/CSA C22.2 No. 210.05
Tinned or bare, stranded or solid copper conductor
Insulation: PVC
Uniform insulation thickness to ensure easy stripping and cutting
Passed UL VW-1 flame test
Application:
For internal wiring of electronic and electrical equipment
Can be substituted by UL10982 & UL3385

Type		SizeAWG	Conductor		Weight KG/KM	Inslulation Thickness mm	OD mm
Type		SizeAWG	Conductor		Weight KG/KM	Inslulation Thickness mm	Down limited		Up Limtied
UL1007	bare copper wire	26	7	0.16	3.55	0.40	1.28	～	1.48
UL1007	bare copper wire	24	11	0.16	4.58	0.40	1.41	～	1.61
UL1007	bare copper wire	22	17	0.16	6.03	0.40	1.56	～	1.76
UL1007	bare copper wire	20	26	0.16	8.09	0.40	1.74	～	1.94
UL1007	bare copper wire	18	41	0.16	11.38	0.40	1.98	～	2.18
UL1007	bare copper wire	16	26	0.254	17.18	0.40	2.36	～	2.56

Type		SizeAWG	Conductor		Weight KG/KM	Inslulation Thickness mm	OD mm
Type		SizeAWG	Conductor		Weight KG/KM	Inslulation Thickness mm	Down limited		Up Limtied
UL1007	tinned copper wire	26	7	0.16	3.55	0.4	1.28	～	1.48
UL1007	tinned copper wire	24	11	0.16	4.58	0.4	1.41	～	1.61
UL1007	tinned copper wire	22	17	0.16	6.03	0.4	1.56	～	1.76
UL1007	tinned copper wire	20	26	0.16	8.09	0.4	1.74	～	1.94
UL1007	tinned copper wire	18	41	0.16	11.38	0.4	1.98	～	2.18
UL1007	tinned copper wire	16	27	0.25	17.18	0.4	2.36	～	2.56

UL1007 18AWG electrical wire electrical cable ECHU Cable E312831
